经久耐用，技术成熟，产品稳定，超高性价比
低压双级压缩永磁变频螺杆空压机技术参数/Technical parameter
型号 Model | 功率 Power (kw) | 排气压力 Pressure (Mpa) | 容积流量 Volume flow (m3/min) | 出口尺寸 Pipe Diameter | 机组重量 Weight (kg) | 外形尺寸 Dimension (mm) |
WA15AMII | 11 | 0.4 | 3.2 | G1 | 500 | 1300*980*1220 |
0.5 | 2.8 |
WA20AMII | 15 | 0.4 | 4.2 | G1 | 550 | 1300*980*1220 |
0.5 | 3.6 |
WA25AMII | 18.5 | 0.4 | 4.5 | G1 1/2 | 700 | 41400*1100*1450 |
0.5 | 4.2 |
WA30AMII | 22 | 0.4 | 6.2 | G1 1/2 | 800 | 1400*1100*1450 |
0.5 | 5.8 |
WA40AMII | 30 | 0.4 | 8.5 | G1 1/2 | 850 | 1400*1100*1450 |
0.5 | 7.5 |
WA50AMII | 37 | 0.4 | 10.3 | G1 1/2 | 1600 | 2100*1440*1650 |
0.5 | 9.5 |
WA60AMII | 45 | 0.4 | 12.2 | G1 1/2 | 1650 | 2100*1440*1650 |
0.5 | 11.5 |
WA75AMII | 55 | 0.4 | 5.5 | DN65 | 2350 | 2450*1700*1765 |
0.5 | 14.5 | G2 1/2 | 1700 | 2100*1440*1650 |
WA100AMII | 75 | 0.4 | 20.5 | DN80 | 2800 | 2600*1900*1890 |
0.5 | 19.5 | DN65 | 2400 | 2450*1700*1765 |
WA12AMII | 90 | 0.4 | 24.5 | DN80 | 2800 | 2600*1900*1890 |
0.5 | 23.0 |
WA150AMII | 110 | 0.4 | 28.0 | DN80 | 2900 | 2600*1900*1890 |
0.5 | 27.5 |
WA180AMII | 132 | 0.4 | 38.0 | DN100 | 4000 | 3250*2100*2200 |
0.5 | 35.0 |
WA220AMII | 160 | 0.4 | 47.0 | DN125 | 5500 | 3550*2300*2300 |
0.5 | 42.0 | DN100 | 4400 | 3250*2100*2200 |
WA250AMII | 185 | 0.4 | 52.0 | DN125 | 5800 | 3550*2300*2300 |
0.5 | 45.0 |
WA270AMII | 200 | 0.4 | 57.0 | DN125 | 6000 | 3550*2300*2300 |
0.5 | 51.0 |
WA300AMII | 220 | 0.4 | 62.0 | DN125 | 8000 | 4300*2300*2430 |
0.5 | 55.0 |
WA350AMII | 250 | 0.4 | 65.0 | DN125 | 8500 | 4300*2300*2430 |
0.5 | 61.0 |
